32+ Hikvision cameras, three face-ID turnstile lanes, 14 ceiling Wi-Fi APs, 48 Cat 6 drops, and a full network rack — installed alongside the interior fit-out so every system was live on opening day.
Skyline Admin
June 5, 2026
RPM Gym needed every low-voltage system in a premium two-floor fitness club ready on the day interior handover happened — not a week later, not after a punch list. That's an operational constraint that drives the entire ELV approach.
Cabling had to be in the ceilings before they closed. Devices had to be installed during the second-fix window. Face-recognition turnstiles had to be enrolled with the founding-member database before the first session ran. And the gypsum trade was on an aggressive parallel schedule, so any rework on our side would have collapsed the critical path.
"Be invisible during build, indispensable on opening day."
That brief drove four operational decisions before we touched a tool.
48 Cat 6 data drops routed through cable tray during MEP works, before ceilings closed. Every drop labelled at both ends, every termination tested with a Fluke certifier. The testing data was archived against the project ID so any future contractor can verify the cable plant.
32+ Hikvision IP cameras across both floors:
Plus 14 ceiling-mounted Omada Wi-Fi 6 access points with overlapping coverage for seamless roaming across training floors, DSPPA zone-audio speakers for the PA system, and three face-ID turnstile lanes — two on the men's entrance, one on the women's.
A full-height network cabinet in the back-of-house with:
The rack was assembled in our workshop before site arrival — fully wired, labelled, tested — and dropped into place on site as a single unit.
Face database loaded, scenes programmed, NVR retention validated, mobile-app live view tested for the operator and owner. Documentation and training delivered the day before handover so reception staff opened the doors knowing every system.
We learned this on a previous job. Devices placed inside high-humidity training rooms need anti-corrosion housings and a 6-month cleaning schedule. RPM Gym got the IP54-rated versions in those rooms even though the budget didn't require it.
The Wi-Fi network is a feature, not infrastructure. Members stream music, video-call their trainers, and post during workouts. We spec'd 14 APs for a layout that would have been fine with 10, just to keep performance smooth during peak hours.
Members forget bands. They lose cards. They show up sweaty and don't want to fish a fob out of a pocket. Face-ID processes them while they walk through the entrance — no hands, no delay, no friction. Three months in, the operator has had zero complaints about turnstile speed.
A full ELV fit-out for a two-floor premium gym (1,200-1,800 m²) typically runs AED 280,000 - AED 480,000 depending on camera count, face-ID quality, audio specification, and network grade. RPM Gym sat in the middle of that range. Annual maintenance contracts on commercial CCTV installations run 8-12% of the install cost.
The single biggest cost variable is face-ID enrolment volume — a 200-member gym is quick to enrol; a 2,000-member chain is a multi-week project on its own.
If you're fitting out a gym, salon, retail space, or any commercial venue and want a realistic ELV scope conversation, reach out.
Minimum viable: 8 cameras (entrance, reception, two training floors, locker-room corridors, two emergency exits, mechanical room) on a 16-channel NVR with 30-day retention. Budget: AED 25,000-40,000. Premium gyms typically go to 30+ cameras with face-ID turnstiles and AI analytics, running AED 80,000-180,000.
Yes — biometric authentication for member access is widely deployed in UAE gyms, hotels, and offices. Operators must comply with PDPL (UAE Personal Data Protection Law) — collecting explicit consent at enrolment, storing biometric templates rather than raw images, and providing a way for members to delete their biometric data when they cancel. We design the consent flow as part of every face-ID project.
For a 1,000-2,000 m² space with 30+ cameras, face-ID access, structured cabling and Wi-Fi: 6-10 weeks total, mostly sequenced against the interior contractor's schedule. The actual ELV work is 3-4 weeks; the rest is waiting for ceiling close, second-fix windows, and pre-opening tests. Small retail (200-500 m²) typically takes 2-3 weeks.
Some Abu Dhabi commercial categories require ADCC (Abu Dhabi Monitoring & Control Centre) integration; gyms generally don't, but this changes — we check the current trade-licence requirement before quoting. ADCC integration adds AED 5,000-10,000 to a CCTV project plus a monthly subscription.
Three layers: monthly camera cleaning (especially in high-humidity gym areas), quarterly firmware updates and storage health checks, and annual audit-grade testing of the entire system. Annual maintenance contracts run 8-12% of the install cost. Without maintenance, expect a major issue within 18-24 months.
Yes. We typically integrate face-ID turnstiles with the gym's existing CRM (Mindbody, Zenoti, custom) via API so a member's access state updates automatically — paused memberships trigger access denial without anyone touching the turnstile system. This is the single most-valued integration for multi-location gym chains.
